Spesifikasi:
Spesifikasi:
Physical Dimensions Length - Width - Height - Weight
Small Passively Damped System Table: 90 - 75 - 83 - 130
Small Actively Damped System Table: 90 - 75 - 81 - 130
Large Actively Damped System Table: 120 - 90 - 86 - 180
Active Anti-Vibration Table (NLO): 180 - 150 - 91 - 475
Active Anti-Vibration Table (NLO): 180 - 180 - 91 - 515
Scanning Module LSM: 980 - 55 - 45 - 22 - 27
Microscope: 47 – 80 - 29 – 39 - 70 – 72 - 37 – 47
Laser and Power Supply module: 60 - 50 - 56 - 70
Airyscan 2: 40 - 20 - 24 – 12
Fiber Optic Cable, UV: 400
Fiber Optic Cable, VIS: 400
Cables: 250
Stands: Upright: Axio Imager.Z2, Axio Examiner.Z1
Inverted: Axio Observer 7 with side port or rear port, AI Sample Finder (optional)
Z Drive: Smallest increment Axio Imager.Z2: 10 nm;
Axio Observer 7: 10 nm;
Axio Examiner: 25 nm;
fast piezo objective or stage focus available; Definite Focus for Axio Observer 7
XY Stage (optional): Motorized XY scanning stage, for Mark & Find function (XYZ) as well as Tile Scan (Mosaic Scan);
smallest increment of 0.25 µm (Axio Observer 7), 0.2 µm (Axio Imager.Z2) or 0.25 µm (Axio Examiner.Z1)
Scanner: Two independent, galvanometric scanning mirrors with ultrashort line and frame flyback
Scanning Resolution: 32 × 1 to 8,192 × 8,192 pixels, also for multiple channels, continuously adjustable
Scanning Speed:
At 512 × 512 pixels: confocal – up to 13 fps; 34-Channel Lambda Scan up to 5 fps; Airyscan SR – up to 4.7 fps;
Multiplex SR-4Y – 25 fps; Multiplex SR-8Y – 47.5 fps; Multiplex CO-8Y – 34.4 fps
19 × 2 speed levels for confocal; 512 × 16 pixels up to 425 fps; up to 6830 lines/sec.
13 × 2 speed levels in Multiplex mode; up to 25 fps for 904 × 904 pixels; up to 17.8 fps at 1,024 × 1,024 pixels
Scanning Zoom: 0.6 × to 40 ×; digitally adjustable in increments of 0.1 (Axio Examiner: 0.7 × to 40 ×)
Scanning Rotation: Can be rotated freely (360 degrees), adjustable in increments of 0.1 degree, freely adjustable XY offset
