Observation Method: Brightfield ✓
Simple Polarized Light ✓
Illuminator: Transmitted Köhler Illuminator: LED Lamp ✓
Focus: Focusing Mechanism: Nosepiece Focus ✓
Intermediate Magnification Changer: Manual Terret ✓
Revolving Nosepiece: Manual: Standard (5 positions): ✓
Stage:
Manual: Manual Stages with Right-Hand Control :
X: 76 mm (3 in.), Y: 52 mm (2 in.)
Mechanical: Plain Stage: Dimensions: 180 mm × 150 mm (7 in. × 6 in.)
Rotatable Graduated Stage: Rotation: 360 degrees
Precision Rotatable Stage: Rotation: 360 degrees
Condenser: Manual: Swing-Out Condenser: NA 0.9/ W.D. 2 mm (1.25X–100X) (built-in)
Operating Environment: Indoor Use:
Ambient Temperature: 5 °C–40 °C (41 °F–104 °F)
Maximum Relative Humidity: 80% for temperatures up to 31 ºC (88 ºF), decreasing linearly through 70% at 34 ºC (93 ºF), 60% at 37 ºC (99 ºF), to 50% relative humidity at 40 ºC (104 ºF)
Supply Voltage Fluctuations: ±10 %
Dimensions (W × D × H) : 274.5 mm × 362 mm × 410 mm (10.8 in. × 14.3 in. × 16.1 in.)
(Standard configuration)
Weight: 17 kg (37.5 lb) (Standard configuration)
