Observation Method: Brightfield: ✓
Darkfield: ✓
Phase Contrast: ✓
Fluorescence (Blue/Green Excitations): ✓
Fluorescence (Ultraviolet Excitations): ✓
Differential Interference Contrast: ✓
Polarized Light: ✓
Simple Polarized Light: ✓
Illuminator:
Transmitted Köhler Illuminator: LED Lamp: ✓
Fluorescence Illuminator: 100 W Mercury Lamp: ✓
Light Guide Illumination: ✓
Focus: Focusing Mechanism: Stage Focus: ✓
Intermediate Magnification Changer: Manual Terret: ✓
Stage: Motorized: Contact your local sales representative to hear
about motorized stage options
Manual: Manual Stages with Right-Hand Control :
X: 76 mm (3 in.), Y: 52 mm (2 in.)
Mechanical:Oil Rectangular Stage with Right-Hand Control:
X: 76 mm (3 in.), Y: 52 mm (2 in.)
Operating Environment: Indoor Use:
Ambient Temperature: 5 °C–40 °C (41 °F–104 °F)
Maximum Relative Humidity: 80% for temperatures up to 31 ºC (88 ºF),
decreasing linearly through 70% at 34 ºC (93 ºF), 60% at 37 ºC (99 ºF),
to 50% relative humidity at 40 ºC (104 ºF)
Supply Voltage Fluctuations: ±10 %
Dimensions (W × D × H) : 294.5 mm × 740.5 mm × 582.5 mm
(12 in. × 29.2 in. × 23 in.) (Epifluorescence configuration)
Weight: 35 kg (Epifluorescence Configuration)
