The CX43 microscopes enable users to remain comfortable during routine microscopy. The microscope frame well fit the hands and the location of the control knobs maximize ergonomics to improve work efficiency. Users can quickly set a specimen with one hand, while adjusting the focus and operating the stage with the other hand with minimal movement. Both microscopes also feature a camera port for digital imaging.
Observation Method: Brightfield: ✓ Darkfield: ✓ Phase Contrast: ✓ Fluorescence (Blue/Green Excitations): ✓ Fluorescence (Ultraviolet Excitations): ✓ Differential Interference Contrast: ✓ Polarized Light: ✓ Simple Polarized Light: ✓ Illuminator: Transmitted Köhler Illuminator: LED Lamp: ✓ Fluorescence Illuminator: 100 W Mercury Lamp: ✓ Light Guide Illumination: ✓ Focus: Focusing Mechanism: Stage Focus: ✓ Intermediate Magnification Changer: Manual Terret: ✓ Stage: Motorized: Contact your local sales representative to hear about motorized stage options Manual: Manual Stages with Right-Hand Control : X: 76 mm (3 in.), Y: 52 mm (2 in.) Mechanical:Oil Rectangular Stage with Right-Hand Control: X: 76 mm (3 in.), Y: 52 mm (2 in.) Operating Environment: Indoor Use: Ambient Temperature: 5 °C–40 °C (41 °F–104 °F) Maximum Relative Humidity: 80% for temperatures up to 31 ºC (88 ºF), decreasing linearly through 70% at 34 ºC (93 ºF), 60% at 37 ºC (99 ºF), to 50% relative humidity at 40 ºC (104 ºF) Supply Voltage Fluctuations: ±10 % Dimensions (W × D × H) : 294.5 mm × 740.5 mm × 582.5 mm (12 in. × 29.2 in. × 23 in.) (Epifluorescence configuration) Weight: 35 kg (Epifluorescence Configuration)
The Olympus CX23 microscope is an economically priced Olympus microscope that achieves high optical and mechanical quality standards for educational applications. The binocular head is tilted and equipped with an Olympus WF eyepiece up to 10x. Simple enough for even first-time microscope users to master, the CX23 achieves high standards of optical and mechanical quality for educational microscopes.
CX33 biological microscopes enable you to remain comfortable during long periods of routine observation. The microscope frame conforms to your hands, and the location of the control knobs maximizes ergonomics to improve work efficiency. With minimal movement, you can quickly set a specimen with one hand, while adjusting the focus and operating the stage with the other hand. The microscopes can also feature an optional camera port for digital imaging.
CX43 biological microscopes enable you to remain comfortable during long periods of routine observation. The microscope frame conforms to your hands, and the location of the control knobs maximizes ergonomics to improve work efficiency. With minimal movement, you can quickly set a specimen with one hand, while adjusting the focus and operating the stage with the other hand. The microscopes can also feature an optional camera port for digital imaging.
