Spesifikasi:
Temperature range for operation with indicated performance
(24 h per day, regardless of whether the microscope is in operation or switched off): 5 – 40 °C
Relative humidity: < 80 % at 40 °C
Atmospheric pressure / altitude: 800 to 1060 hPa / ≤ 2000 m above sea level
Pollution degree: 2
Nominal AC voltage L/N/PE: 100 to 240 VAC ± 10 %
Nominal frequency: 50/60 Hz
Max. current: 1.4 A
Rating for microscope stand: 24 VDC, 5 A
Protection Class: IP20 (IEC 60529)
Overvoltage category: II
Optical system: Infinite, ICS
Nosepiece: 6× nosepiece, encoded
Focus Manual: coarse / fine focus; 13 mm focus range with adjustable focus stop
Camera specification: High sensitivity 5 MP global shutter CMOS sensor, 3.45 micrometer pixel size
Objectives (included): LD A-Plan 5×, 10×, 20× and 40× (all Ph)
Optional objectives: Large choice of long distance and coverslip-corrected objectives
Contrast methods: Brightfield, phase contrast, fluorescence contrast
Dimensions: 503 × 363 × 505 (L × W × H in mm)
Weight: 18.2 kg
