Spesifikasi:
Dimensions (width × depth × height)
Systems with fixed-Köhler stands: approx. 208 mm × 296 mm × 398 mm
Systems with full-Köhler stands: approx. 208 mm × 296 mm × 398 mm
Systems with Binocular tube HD 25°/20 w/int cam 8MPx:
approx. 208 mm × 296 mm × 398 mm
Weight
Systems with fixed-Köhler stands: approx. 8.5 – 10.5 kg *
Systems with full-Köhler stands: approx. 9.4 – 11.4 kg *
Systems with binocular tube HD 25°/20 w/int cam 8MPx: approx. 9.6 – 12.0 kg *
Operating data
Protection class: II
Protection type: IP20
Electrical safety: in compliance with DIN EN 61010-1 (IEC 61010-1)
including CSA and UL directives
Pollution degree: 2
Overvoltage category: II
Radio interference suppression: in accordance with EN 61326
Line voltage: 100 to 240 V (±10 %) wide-range input power supply,
i.e. voltage setting of the instrument need not be changed!
Line frequency: 50 / 60 Hz
Power consumption: 70 VA; secondary voltage of external power supply 12 V
Plug-in power unit output : 12 V DC; max. 2.5 A
Microscope 12 V / 6 V DC: adjustable from 1.5 V to 6 V
LED class of complete device: 3B
