Spesifikasi:
Spatial Resolution [a]: 0.95 μm
Minimum Achievable Voxel [b]: 0.5 µm
Achievable Voxel at Working Distance [b,c]:
0.5 µm / 0.5 mm; 0.8 µm / 2.5 mm; 2.5 µm / 12.5 mm; 4.0 µm / 25 mm; 12.1 µm / 100 mm
Type: Spot Stabilized, Sealed Transmission
Tube Voltage Range: 30 – 160 kV
Maximum Output: 10 W
High Speed, Large Array CMOS Flat Panel: 3072 1944 pixels
Single Field of View (diameter / height): 140 mm / 93 mm
Maximum Field of View (diameter / height): 140 mm / 165 mm
Sample Stage (load capacity): 25 kg
Sample Stage Travel (x, y, z): 50, 100, 50 mm
Stage Travel (rotation): 360º
Source Travel (z): 190 mm
Detector Travel (z): 475 mm
Sample Size Limit: 300 mm
