Spesifikasi:
Minimum Achievable Voxel [a]: 0.5 µm
Spatial Resolution [b]: 0.95 µm
Achievable Voxel at Working Distance [a,c]:
0.5 µm at 0.5 mm; 0.8 µm at 2.5 mm; 2.5 µm at 12.5 mm; 4.0 µm at 25 mm; 12.1 µm at 100 mm
Grain Detectability: 20 µm
Grain Orientation Angular Resolution: 0.1°
Crystal Symmetries: Cubic, Hexagonal, Trigonal, Tetragonal, Orthorhombic, Monoclinic, Triclinic
DCT Advanced Acquisition Modes: Three DCT modes, including Helical Phyllotaxis, Helical Phyllotaxis-Raster, and Helical Phyllotaxis-HART
DCT X-ray Source Apertures: Set of three self-aligning DCT apertures
DCT Detector Beamstops: Set of six zero-order beamstops
DCT Reconstruction and Visualization: GrainMapper3D powered by Xnovo Technology
Type: Spot Stabilized, Sealed Transmission
Tube Voltage Range: 30 – 160 kV
Maximum Output: 10 W
High Speed, Large Array CMOS Flat Panel: 3072 1944 pixels
Single Field of View (diameter / height): 140 mm / 93 mm
Maximum Field of View (diameter / height): 140 mm / 165 mm
Chassis: Proven stable Xradia Versa platform
Vibration Isolation: Granite base
Temperature Control: Temperature-stabilized interior
Drift Correction Capabilities: Adaptive Motion, Sample Drift, and Thermal tracking and compensation; plus, proprietary advanced methods
Artifact-Free Imaging Methods: Dynamic Ring Removal; Secondary Referencing; plus, proprietary advanced methods Sample Stage (load capacity): 25 kg
Sample Stage Travel (x, y, z, θ): 50, 100, 50 mm, 360° motorized micro-positioning capability
Sample Region-of-Interest (ROI): Intuitive 3D navigation for precise ROI positioning enabled by innovative sample stage architecture
Source Travel (z): 190 mm
Detector Travel (z): 475 mm
