Weighing range : 70 g
Repeatability, average :
for initial sample weight approx. > 1 g: ± 0.2 %
for initial sample weight approx. > 5 g: ± 0.05 %
Readability : 1 mg; 0.01%
Measurement display : Moisture content in %M and g | dry matter in %S and g | ATRO in %M/S
Temperature range and settings : 40°C–160°C, stand-by temperature selectable from 40 – 100°C in increments of 1°C
Sample heating : Infrared metal heating elements
Heating programs : Standard drying, gentle drying
Access to sample chamber : Removable hood with wide opening angle, SoftClose mechanism
Measuring program : 1 program saved in a non-volatile memory (freely selectable method parameters)
Memory for data storage : Results are saved until the start of the next measurement
Operator guidance features : Intuitive user interface, including touch screen and easy-to-understand menu guidance
Language selection : English, German, French, Spanish, Italian, Russian, Chinese, Polish, Japanese, Portuguese,
Turkish
Status light : Displays the status “analysis running / START”, “analysis completed / STOP” or “analysis error”
Sample inspection : LED-illuminated sample chamber, inspection window with grid above the hood
Draft shield Integrated draft shield
Cleaning : Removable hood, inspection window with grid and sample chamber plate for easy cleaning
in the dishwasher
Data interface Mini USB :
Automatic detection of the Sartorius printers YDP30 and YDP40
Direct data transfer to Microsoft® Windows programs without any additional software
Programmable data output interval
Data transfer protocols SBI, table format, text format
Frequency : 50/60 Hz
Power consumption : Max. 640 VA
Temperature range : 10°C – 30°C
Housing dimensions (W + D + H) : 215 + 400 + 210 mm
Weight : Approx. 6.2 kg
