Bandwidth : 70MHz
Channels : 2
Sampling rate : 1GS/s (single channel), 500MS/s (dual channels)
Rise time : ≤5ns
Memory depth : 25kpts
Waveform capture rate : ≥20,000wfms/s
Vertical scale (V/div) : 1mV/div~20V/div (1MΩ)
Time base scale (s/div) : 2ns/div~50s/div
Input impedance : (1MΩ±2%)//(22pF±3pF)
Storage methods : Setup, wave, bitmap
Trigger types : Edge, pulse width, slope, video, runt, window
Number of measurements : Display 5 measurements at the same time
Measurement statistics : Average, Max, Min, standard deviation, number of measurements
Frequency counter : 6 bits
Interfaces : USB-OTG, Pass/Fail
Power : 100~240V ACrms, 50Hz/60Hz
Display : 8-inch TFT LCD, WVGA (800 x 480)
Product color : White and grey
Product size : 336mm x 164mm x 108mm
Product net weight : 3.5kg
