Output voltage : -0% +20% at rated load or less
Voltage display : ±3% ±3 digits ±0.5% of rated voltage
Short circuit current : 1.5 mA nominal test current
Test current on load 1: mA at min pass values of insulation
Measurement accuracy :
1000 Volts 10 kΩ ~ 999 MΩ : ±3% ±2 digits
500 Volts 10 kΩ ~ 500 MΩ : ±3% ±2 digits
>500 MΩ ±10% ±4 digits
250 Volts 10 kΩ ~ 250 MΩ : ±3% ±2 digits
>250 MΩ ±10% ±4 digits
100 Volts 10 kΩ ~ 100 MΩ : ±3% ±2 digits
>100 MΩ ±10% ±4 digits
Resistance and continuity :
0.01 Ω ~ 99.9 Ω ±2% ±2 digits
100 Ω ~ 99.9 kΩ ±5% ±2 digits
Open circuit voltage 5 V ±1 V
Test current (0 Ω ~ 2 Ω) 205 mA ± 5 mA
15 mA ±5 mA (user selectable)
Calibration temperature : +20 °C
Temperature co-efficient : <0,1% per °C
Weight : 1 kg (with batteries, excluding case)
Dimensions : 150 mm H x 85 mm W x 235 mm D
