Measurement lines : Single-phase 2-wires
Measurement items : Voltage, Current, Active power, Apparent power, Power factor
Measurement range :
[Voltage] : 200 V AC (300 V Max.)
[Current] : 50/ 200/ 500 mA, 2/ 5/ 20 A AC (30 A Max.)
[Power] : 10.000 W to 4.000 kW (combination of voltage and current ranges)
Input resistance (50/60 Hz) : [Voltage] 2.4 MΩ, [Current] 7 mΩ or less (direct input)
Basic accuracy :
[Guaranteed for 1 year, Voltage, Current, Active power] ±0.1 % rdg. ±0.1 % f.s. (45 Hz to 66 Hz, input current 20 A or less)
[Guaranteed for 3 years, Voltage, Current, Active power] ±0.1 % rdg. ±0.2 % f.s. (45 Hz to 66 Hz, input current 20 A or less)
Display refresh rate : 5 times/s
Frequency characteristics : 45 Hz to 5 kHz
D/A output : 3 channels outputs simultaneously for voltage, current, active power
+2 V DC f.s.
Functions : Scaling (VT, CT ratio settings), Average function
Interfaces : RS-232C standard, GP-IB (Model 3333-01 only)
Power supply : 100 to 240 V AC, 50/60 Hz, 20 VA max.
Dimensions : 160 mm (6.30 in) W × 100 mm (3.94 in) H × 227 mm (8.94 in) D
Weight : 1.9 kg (67.0 oz)
