Readability (mg) : 10
Maximun capacity : 10200
Readability (at 5% load) (mg)
Standard deviation of load values, tolerancing : 15
Standard deviation of load values, typical value : 20
Readability (at aprox 100% load)
Standard deviation of load values, tolerancing : 25
Standard deviation of load values, typical value : 30
Linearity deviation (mg)
Toleramce : 25
Typical value : 30
Deviation when load if off-center positions according OIMLR76 (µg)
Test weight : 5000
Tolerance (mg) : 25
Typical value (mg) : 30
Sensitivity drift between (+10C-30C) ppm/K : 6
Tare max capacity <100% of max capacity
Accuracy class (according to directive 2014I31IEU) : I
Verification scale interval (e) (according to directive 2014I31IEU) : 100
Min load (according to directive 2014I31IEU) (mg) : 1000
Min initial weighing according to USP (United States Pharmacopeia chap.41)
Optimum min initial weighing (mg) : 820
Typical min initial weighing (mg) : 1.3
Typical stabilization time (s) : 5
Typical measurement time (s) : 8
Recommended calibration weight
External calibrated test weight (g) : 5000/10000
Accuracy class (in accordance with OIMLR111-1) : F1
Temp in operation : 18C-23C
Warm-up temp fluctuation : ≤1C/H
Relative humidity : 50%-75%
Power supply : 100V-240V AC Freq : 50/60Hz Current : 1.0A-0.5A
Dimension (mm) : 240x425x112
Weighing pan size (mm) : ɸ206*206
Net weight approx. (kg) : 7.9
