Readability (mg) : 1
Maximun capacity : 320
Readability (at 5% load) (mg)
Standard deviation of load values, tolerancing : 1
Standard deviation of load values, typical value : 1.5
Readability (at aprox 100% load)
Standard deviation of load values, tolerancing : 2
Standard deviation of load values, typical value : 2.5
Linearity deviation (mg)
Toleramce : 2
Typical value : 2.5
Deviation when load if off-center positions according OIMLR76 (µg)
Test weight : 200
Tolerance (mg) : 2
Typical value (mg) : 2.5
Sensitivity drift between (+10C-30C) ppm/K : 5
Tare max capacity <100% of max capacity
Accuracy class (according to directive 2014I31IEU) : II
Verification scale interval (e) (according to directive 2014I31IEU) : 10
Min load (according to directive 2014I31IEU) (mg) : 1
Min initial weighing according to USP (United States Pharmacopeia chap.41)
Optimum min initial weighing (mg) : 82
Typical min initial weighing (mg) : 1.3
Typical stabilization time (s) : 2
Typical measurement time (s) : 3
Recommended calibration weight
External calibrated test weight (g) : 200
Accuracy class (in accordance with OIMLR111-1) : F1
Temp in operation : 18C-23C
Warm-up temp fluctuation : ≤1C/H
Relative humidity : 50%-75%
Power supply : 100V-240V AC Freq : 50/60Hz Current : 1.0A-0.5A
Dimension (mm) : 240x430x380
Weighing pan size (mm) : ɸ14*140
Weight chamber height (mm) : 248
Net weight approx. (kg) : 9.5
