Measurement range 1 : -14 psi to 36 psi
Measurement range 2 : -12 to 300 psi
Resolution 1 : 0.001 psi
Resolution 2 : 0.01 psi
Accuracy 1 : 0.025% of full scale
Accuracy 2 : 0.025% of full scale
mA measure range : 0 to 24 mA
mA Resolution : 0.001 mA
mA Accuracy : ±0.015% of rdg
V DC measure range : 0 to 30 V DC
V DC Resolution : 0.001 V
V DC Accuracy : ±0.015% of rdg
Temperature measure (RTD/ Ohms) range : -40°C to 150°C
Temperature Resolution : 0.01°C
Temperature Accuracy : ±0.015% of rdg / ±0.02 ohms
Loop power supply : 24 V
Available Pressure Engineering Units : psi, bar, mbar, kPa, kgcm2, cmH2O @ 4°C, cmH2O @ 20°C, mH2O @ 4°C, mH2O @ 20°C, inH2O @ 4°C, inH2O @ 20°C, inH2O @ 60°F, mmHg @ 0°C, inHg @ 0°C, ftH2O @ 4°C, ftH2O @ 20°C, ftH2O @ 60°F
Operating temperature : -10°C to +50°C
Storage temperature (without batteries) : -20°C to +60°C
Altitude : 2,000 m
Ingress protection : IP-40
Power requirements : 6.0 V DC
Battery life : >35 hours, typical usage
Batteries required : (4) Standard AA cells
Connectors/ports pressure : Two, 1/8 in NPT, 700P Series Pressure Module; RTD Probe
Dimensions (H x W x D) : 7.9 x 4.3 x 2.3 in (20 x 11 x 5.8 cm)
Weight : 3 kg (1 lb 3 oz
