Measurement range : -12 to 30 psi
Resolution : 0.001 psi
Accuracy : ±0.025% of full scale, 6 months
Temperature effect (all ranges) : Add ±0.002% F.S./°C for temps outside of 15°C to 35°C
mA DC (simulation and measurement) : 0-24 mA DC
Resolution : 0.001 mA
Accuracy : ±0.015% of reading ±2 counts
Volts DC (measurement only) : 30 V DC
Resolution : 0.001 V
Accuracy : ±0.015% of reading ±2 counts
Temperature (measurement only, Pt100 RTD) : -50 to 150°C
Resolution : 0.01°C
Accuracy : ±0.1°C
Loop power supply : 24 V DC
Operating temperature : -10°C to +50°C
Storage temperature (with batteries) : Per battery manufacturer's specification within storage specification below
Storage temperature (without batteries) : -20°C to +60°C
Battery : Eight (8) standard Alkaline AA batteries
Battery life : 300 pump cycles to 150 psi minimum; 1000 pump cycles to 30 psi; 100 pump cycles to 300 psi minimum
Engineering Units (Configurable) : psi, bar, mbar, kPa, kgcm2, cmH2O @ 4°C, cmH2O @ 20°C, mH2O @ 4°C, mH2O @ 20°C, inH2O @ 4°C, inH2O @ 20°C, inH2O @ 60°F, mmHg @ 0°C, inHg @ 0°C, ftH2O @ 4°C, ftH2O @ 20°C, ftH2O @ 60°F
Dimensions (H x W x D) : 24.13 x 11.18 x 7 cm (9.5 x 4.4 x 2.8 in)
Weight : With holster 1.2 kg (2.5 lb)
