Structure : Corrosion-resistant technopolymer
Delay time (devarda alloy analysis) : 0 - 99 min
Reproducibility (RSD) : ≤ 1 %
Detection limit : ≥ 0.1 mg N
Sodium hydroxide addition : automatic
Boric acid addition : automatic
Water volume : 0 - 200 ml
Distillation residues removal : automatic
Tap water consumption : from 0,5 l/min at 15 °C – from 1 l/min at 30 °C
On-board archive for data storage : Yes
Display : 6" color touch screen
Protocol library : 55 methods: 31 pre-installed + 24 customizable
Recovery : ≥ 99.5 % at nitrogen levels between 1 and 200 mg N
Analysis time : from 4 minutes (including titration)
Water addition : automatic
Sodium hydroxide volume : 0 - 150 ml
Boric acid volume : 0 - 100 ml
Steam flow regulation : from 10 to 100 %
Connections : Ethernet, 2 x USB and RS232 for PC, printer, mouse, pen drive, balance
Power : 2200 W
Dimensions (WxHxD) : 385x780x416 mm (15.2x30.7x16.4 in)
Weight : 31 kg / 68.3 lb

UDK 169 & AutoKjel :
Autosampler capacity : 24-pos. carousel, 250 ml test tubes (included with AutoKjel) 21-pos. carousel, 400 ml test tubes (optional)
Power : 2250 W
Dimensions (WxHxD) : 830x1730x640 mm (32.7x68.1x25.2 in)
Weight : 131 kg (288.8 lb)
