Measurement Method : Determination of the angle of total reflection of the D-line of sodium (589.3 nm)
Refractive Index :
Measurement range : 1.32 – 1.50 (PX), 1.32 – 1.65 (GS)
Resolution : 0.0001
Accuracy : ± 0.0005
Brix % (%) :
Measurement range : 0 – 85 Brix% (PX), 0 – 100 Brix% (GS)
Resolution : 0.1 Brix%
Accuracy : ± 0.2 Brix%
Temperature (°C or °F) :
Measurement range : 10 – 40 °C
Resolution : 0.1 °C
Display : °C or °F
Ambient temperature : 5 – 35 °C
Measurement Units :
nD, nD temperature compensated, Brix%, HFCS42, HFCS55, T.A. 1990, °KMW (Babo), °Baume, °Oechsle (D, CH),
w/w%, v/v%, specific gravity and freezing point (°C or °F) for ethanol and NaCl, w/w%, v/v% and freezing point (°C or °F) for ethylene glycol and propylene glycol, w/w% and v/v% for isopropanol, user defined unit
Temperature Compensation :
With user-defined temperature compensation coefficient (nD temperature compensated, user defined), or automatically (all other units). Up to 10 temperature correction coefficients can be stored in the instrument
Calibration : With pure water
Data Memory : Up to 1100 results (measured value, sample and instrument identification, temperature correction coefficient, date, and time)
Display : Backlit LC-Display
Interface : Infrared for data transfer to PC and printer (IrDA or RS232C protocol)
Batteries : 2 x LR3, 1.5 V, type AAA with approximately 60 hours battery life
Materials :
Housing : PBT
Measurement cell (GS) : Sapphire, hard gold plated brass
Materials with sample contact (GS) : Sapphire, gold, PBT
Weight : Approximately 250 g
