Evaporation Capacity : Max.4.0 L/h (water vapor volume)
Motor Lift : Automatic
Ultimate Vacuum : Less 2.6 hpa
Rotation Speed : 10-150 rpm
Display : LCD (temperature/speed/clockwise and Anti-clockwise/time)
Temperature control method : Micro processer PID control
Heating Temperature Range : Room temp. to 180°C (both water and oil)
Control Accuracy : water: ±1°C oil: ±3°C
Stroke Displacement : Automatic 180 mm
Sample Flask : Round flask 20L
Receiving Flask : Round flask 10 L with drain valve
Adjustable Immersion Angle : No
Condenser : Two-section vertical triple serpentine condenser, cooling surface 1.2 m²
Takeover Caliber : Cooling/suction nozzle outer diameter 16 mm, vacuum pump nozzle outer diameter 16 mm
Heating Bath Size : ɸ450×240 mm
Dimension[L×W×H] : 1160x600x1860 mm
Voltage / Frequency : 220 V/ 50/60 Hz
Power : 4600 W
Notes : Three-layer high-efficiency condensing tube with large condensation area and strong evaporation capacity, ensuring efficient sample recovery. A switching valve for continuous collection without compromising the system vacuum and solvent distillation.
