Maximum voltage applied between any terminal and earth ground or between any two terminals : 30 V
DC mA Measurement :
Resolution : 0-24 mA
Range : 0.001 mA
Accuracy (% of reading + counts) : 0.010% + 2 μA
Temperature coefficient : ± (0.002% of reading + 0.002% of range) /°C ( <18 °C or >28 °C)
Millivolt Measurement and Source :
Resolution : -10 mV to 75 mV
Range : 0.01 mV
Accuracy (% of reading +counts) : 0.015% + 10 μA
Temperature coefficient : ± (0.002% of reading + 0.002% of range) /°C ( <18 °C or >28 °C)
Operating temperature : -10 °C to 50 °C
Storage temperature : - 30 °C to 60 °C
Operating altitude : 2,000 meters
Storage altitude : 12,000 meters
Vibration requirements : MIL-T-28800E, Class 2
Drop text requirements : 1 meter
IP Rating : IEC 60529: IP52
Electromagnetic environment : IEC 61326-1, Portable
Safety : IEC 61010-1, Max 30 V to earth, Pollution Degree 2
Power supply : 4 AA NEDA 1.5A IEC LR6 batteries
Size (H x W x L) : 52.5 mm x 84 mm x 188.5 mm
Weight : 515 g
