Temperature Range : 100°C to 1210°C
Display Accuracy :
±1.2°C @ 100°C
±1.2°C @ 300°C
±1.2°C @ 600°C
±1.6°C @ 900°C
±2.0°C @ 1210°C
Stability : ±0.1°C
Axial Uniformity (20mm zone) :
±0.6°C @ 100°C
±1.2°C @ 300°C
±1.5°C @ 600°C
±1.5°C @ 900°C
±1.5°C @ 1210°C
Radial Uniformity :
±0.2°C @ 100°C
±0.3°C @ 300°C
±0.4°C @ 600°C
±0.8°C @ 900°C
±1°C @ 1210°C
Loading Effect : ±0.5°C
Environmental Conditions : 8°C to 38°C guaranteed accuracy 0°C to 50°C, 0% to 90% RH non-condensing,
3000 M altitude for normal operation
Storage Conditions : -20°C to 60°C
Immersion Depth :
XR style inserts = 138 mm (5.43")
XS style inserts = 116 mm (4.57")
(see insert ordering info for more details)
Insert Size - OD : 24.8 mm (0.98 inches)
Heating Time : 50 min: 23°C to 1210°C
Cooling Time : 50 mins:1210°C to 300°C / 50 mins: 300°C to 50°C
Typical Time to Stability : 15 min
Resolution : 0.01°C
Units : °C, °F, and K
Display : 6.5 in (165 mm) color touch screen
Power Requirements : 90-254 VAC, 45-65 Hz, 580 W
Communication : USB A, USB B, RJ45, WiFi, Bluetooth
Localization : English, Chinese, Japanese, Russian, German
Size (H x W x D) : 345 x 170 x 330 mm (13.6 x 6.7 x 13.0 in)
Weight : 10.6 kg (23.4 lbs)
