Input
Rated power : 2200 VA
Voltage : 220-230-240 Vac
Voltage tolerance : 140 Vac < Vin < 276 Vac @50% LOAD / 184 Vac < Vin < 276 Vac @ 100% LOAD
Frequency : 50/60 Hz
Frequency tolerance : 50 Hz ± 5% / 60 Hz ± 5%
Power factor : > 0.99
Current distorsion : ≤7%
By Pass
Voltage tolerance : 180 - 264 Vac
Frequency tolerance : Frequency selected (from ±0.Hz to ±5Hz configurable)
Number phases : 1
Output and Inverter Output
Rated power : 2200 VA
Active power : 1980 W
Number phases : 1
Crest factor (Ipeak/Irms) : 3 : 1
Waveform : Sinewave
Frequency : Can be selected: 50 Hz or 60 Hz or self-learning
Voltage distortion with distorcing load : < 4%
Voltage distortion with linear load : < 2%
Overload Times
100% < Load < 110% : 2 minutes
125% = Load < 150% : 5 seconds
Load > 150% : 1 second
Batteries
Type : VRLA AGM lead, maintenance-free
Typical recharge time : N. A.
Enviromental
Altitude max : 6000 m
Color : Black
Communication : USB / DB9 with RS232 and contacts / Slot for communication interface
Safety compliance : EN 62040-1:2008; EN 62040-1/EC:2009; EN 62040-1/A1:2013 and Directive 2014/35/EU
EMC conformance : EN 62040-2 and Directive 2014/30/EU
Accessories provided : Power cable, IEC-IEC cable, serial cable, USB cable, safety manual, quick start
Protection rating : IP20
Surge capability : 300 joule
Marks : CE, GS/NEMKO
Line-Interactive/Smart Active efficiency : 98%
Noise (at 1 m) : < 40 dBA @ 1 m
Operating temperature : 0°C / +40°C
Relative humidity : < 95% not condensed
Weight : 14 kg
Dimensions (h w d) : 190x446x333 mm

*) ER models do not include batteries and rack batteries
