Input
Dual Input : no
Rated power : 10000 VA
Voltage : 380-400-415 Vac (3W+N+PE) 220-230-240 Vac (1W+N+PE)
Voltage tolerance : 242 Vac < Vin < 478 Vac @50% LOAD / 318 Vac < Vin < 478 Vac @ 100% LOAD (3W+N+PE) 140 Vac < Vin < 276 Vac @50% LOAD / 184 Vac < Vin < 276 Vac @ 100% LOAD (1W+N+PE)
Frequency : 50/60 Hz ± 5 Hz
Frequency tolerance : 50 Hz ± 20% / 60 Hz ± 20%
Power factor : >0.98
Current distorsion : ≤2%
By Pass
Voltage tolerance : 180÷264 Vac (selectable in Economy Mode and SMART ACTIVE Mode)
Frequency tolerance : Selected frequency ± 5% (user configurable)
Number phases : 1
Output and Inverter Output
Rated power : 10000 VA
Active power : 10000 W
Crest factor (Ipeak/Irms) : 3 : 1
Waveform : Sinewave
Frequency : 50/60 Hz selectable
Voltage distortion with distorcing load : <3%
Voltage distortion with linear load : <1%
Inverter efficiency at rated load : 95% %
Overload Times
100% < Load < 110% : activates the bypass after 10 min Continues to work on by-pass
110% < Load < 133% : activates the bypass after 1 min shut down after 1 hour
133% < Load < 150% : activates the bypass after 5 s shut down after 10 min
Load > 150% : activates the bypass instantaneously shutdown after 3 s (load > 150%) shutdown after 2 s (load > 200%)
Batteries
Type : VRLA AGM lead, maintenance-free
Typical recharge time : 4÷6 h
Maximum recharge current : 6 A
Options
Parallel kit (to order with the UPS) : Yes
Enviromental
Altitude max : 1000 m at nominal power (-1% power for every 100 m above 1000 m) 4000 m maximum
Color : Black RAL 9005
Communication : USB / DB9 with RS232 and contacts / Slot for communication interface
Safety compliance : EN 62040-1:2008; EN 62040-1/EC:2009; EN 62040-1/A1:2013 and Directive 2014/35/EU
EMC conformance : EN 62040-2 and Directive 2014/30/EU
Accessories provided : USB cable
Protection rating : IP 20
Surge capability : 1 VDR x 300 Joules
Marks : CE
Protections : Overload - short-circuit - overvoltage - undervoltage - temperature - low battery
AC/AC efficiency : 95%
Line-Interactive/Smart Active efficiency : 98%
Noise (at 1 m) : <48 dBA
Operating temperature : 0 ÷ 40 °C
Relative humidity : 5 - 95% no condensing
Output sockets : Terminal block + 2 IEC 320 C13
Input phases : 1
Output phases : 1
Weight : 28 kg
Dimensions (h w d) : 500 x 250 x 698 mm

*) ER models do not include batteries and rack batteries
