Parameter measurement : vibration level, bearing condition and temperature at the same time
Vibration sensor : IEPE type accelerometer
Measurement range : 50(g)
Sensitivity : 100 (mV/g) typical
Frequency response : 1-8 kHz (1dB), 0.3-10 kHz (3dB)
Resonance frequency : 34 kHz
Non-lineariry : 1kHz
Transverse sensitivity : 5%
Shock limit : 5000g
Residual noise : 0.0004 (g RMS)
Temperature sesnor : infrared thermometer
Resolution : 0.1C
Measurement range temperature : 40 C - 115C
Band & resolution : 1kHz (1600 lines or 10kHz (6400 lines)
Processor : ARM Cortex-A8, 1GHz
Display : 3.5" color TFT LCD, 240X320
Storage : 24G flash memory
Input channels : 1 analog & 1 digital input
Input connector : 8 pin lemo connector
Input range : 5V
Input coupling : IEPE, 2mA/19V +1V
A/D resolution : 24 bits
Max. sampling rate : 25.6 kHz
Max. frequency : 10kHz
Analog high pass filter : -10 at 3Hz, -5% at 5Hz
Max. input voltage : +20V
Power supply : 18650 battery x 2
Battery life : 6 hours
USB : 2.0 client, type-C connector
Bluetooth : 4.1 for headset
WIFI : 802.11 b/g 2.4GHz
Camera : 640 x480 pixels
Housing : ABS plastic and rubber sleeve
Certification : IP65, CE mark, rohs
Dimension : 204x85x45 mm
Weight : 0.49 kg
