Ident. No : 0025000323
Viscosity Measuring Range : 320,000,000 mPas
Viscosity Accuracy (FSR) : 1 %
Viscosity Repeatibility (FSR) : 0.2 %
Spring torque : 5.7496 mNm
Guard rail : me-vi
Measuring spindle series : SP set-2
Motor rating output : 4.8 W
Overload protection : yes
Direction of rotation : right
Display : TFT
Speed display : TFT
Speed range : 0.01 - 200 rpm
Setting accuracy speed : 0.01 ±rpm
Speed control : TFT
Torque display : yes
Torque measurement : yes
Timer : yes
Timer display : TFT
Time setting range : 0.017 - 6000 min
Temperature measurement resolution : 0.1 K
Working temperature display : TFT
Connection for ext. temperature sensor : PT 100
Graph function : yes
Operating mode : timer and continuous operation
Calibration option : yes
Touch function : yes
Pemitted density : 9999 kg/dm3
Working temperature : -100 - 300 °C
Fastening on stand : extension arm
Support rod diameter (with integrated fastening on stand) : 16 mm
Telescope stand stroke : 200 mm
Plug-in coupling (Ø) : 12 mm
Basic container volume : 600 ml
Stand : Rotastand
Stroke max. : 200 mm
Diameter : 16 mm
Dynamic load : 5 kg
Permissible ambient temperature : 0 - 40 °C
Permissible relative humidity : 80 %
Protection class according to DIN EN 60529 : IP 40
RS 232 interface : yes
USB interface : yes
Voltage : 100 - 240 V
Frequency : 50/60 Hz
Power input : 24 W
Power input standby : 0.06 W
DC Voltage : 24 V=
Current consumption : 1000 mA
Dimensions (W x H x D) : 351 x 629 x 372 mm
Weight : 7.1 kg
