Display mode : Transmission (%), absorbance, concentration
Optics : Deuterium lamp (UV), halogen lamp (VIS), Czerny-Turner monochromator, silicon photodiode detector
Wavelength range : 190–1100 nm
Wavelength accuracy : ±1 nm (200–900 nm)
Wavelength reproducibility : <0.1 nm
Wavelength resolution : 0.1 nm
Scan speed : 900 nm/min (in 1-nm increments)
Spectral bandwidth : 2 nm (1.5–2.9 nm at 656 nm, 1 nm at the D2 line)
Photometric measurement range : ±3 Abs (200–900 nm)
Photometric accuracy : 5 mAbs at 0.0–0.5 Abs, <1% at 0.5–2.0 Abs at 546 nm
Photometric linearity : <0.5% to 2 Abs, ≤1% at >2 Abs with neutral glass at 546 nm
Scattered light : KI solution at 220 nm <3.3 Abs / <0.05%
Photometric drift : ±0.0034 Abs
Long-term stability : Zero point at 546 nm for 10 hours ≤0.0034 Abs
Measurement technology : Reference beam technology for compensation of lamp ageing and mains fluctuations
Modules : Adapter for rectangular cells (10 mm, 20 mm, 50 mm, 1 inch) and round cells (1 inch);
carousel holder for seven rectangular cells (10 mm), e. g. for enzymology; sipper module for pour-through cells
Test recognition : IBR+ barcode reading system for automatic recognition of 2D barcode cuvette tests
Data storage : 5000 measurement values, 50 scans, 50 time intervals
User programmes 200
Dimensions / weight : 215 × 500 × 460 mm (H × W × D) / 11 kg
Interfaces : 2 × USB type A, 1 × USB type B, 1 × Ethernet
