Range : 1 ppm to 5%
Resolution : 0.1ppm to 0.0001%
Result Units : %, ppm, ppt, mg/g, μg/g, mg, μg, mg/mL, μg/mL, mg Br/100g, g Br/100g, mg Br, g Br
Sample Types : liquid or solid with external dissolution / extraction
Pre-Titration Conditioning : automatic
Background Drift Correction : automatic or user-selectable value
Endpoint Criteria : fixed mV persistence, relative drift stop or absolute drift stop
Dosing : dynamic
Result Statistic : mean, standard deviation
Generator Configuration : diaphragm or diaphragm-less
Generator Current Control : automatic or fixed (400 mA)
Generator Type Detection : automatic
Titration Vessel : operating volume between 100 – 200 mL
Solvent Handling System : sealed system with integrated diaphragm air pump and beaker adapter
Sensor Type : Hi76330 dual platinum pin polarization electrode
Sensor Connection : BNC
Polarization Current : 1, 2, 5, or 10 μA
Voltage Range : 2 mV to 1100 mV
Voltage Resolution : 0.1 mV
Accuracy (@25ºC/77ºF) : ±0.1%
Programmable Stirrer : magnetic, optically regulated, digital stirrer; 200 to 2000 rpm; resolution 100 rpm
Display : 5.7” (320 x 240 pixel) backlit color LCD
Methods : up to 100 (standard and user) methods
Logging Data : up to 100 complete titration reports and drift rate reports can be stored
Peripherals (Rear) : connections for VGA display, PC-keyboard, parallel printer, USB device input, RS232
GLP Conformity : Good Laboratory Practice and instrument data storage and printing
Languages : English, Portuguese. Spanish, and French
Enclosure Material : ABS plastic and steel
Keypad : polycarbonate
Operating Environment : 10 to 40°C (50 to 104°F), up to 95% RH
Storage Environment : -20 to 70°C (-4 to 158°F), up to 95% RH
Dimensions : 390 x 350 x 380 mm (15.3 x 13.8 x 14.9”)
Weight : approximately 10 kg (22 lbs.)
