Operating mode : Transmittance (%), Absorbance and Concentration
Source lamp : Xenon Flash
Wavelength range : 340 to 800 nm
Wavelength accuracy : ± 2 nm (range 340 - 800nm)
Wavelength selection : Automatic
Wavelength reproducibility : ± 0.1 nm
Spectral bandwidth : 5 nm
Photometric measuring range : 0 to 3 Abs (wavelength range 340 – 800 nm)
Photometric accuracy : ± 0.003 Abs @ 0.0 - 0.5 Abs
Photometric linearity : < 0.5 % (0.5 - 2.0 Abs)
Stray light : < 0.1 %T at 340 nm with NaNO2
Display : Graphical display 240 x 160 pixel (LCD, b/w, backlit)
Data logger : 500 measured values (Result, Date, Time, Sample ID, User ID acc. to GLP)
Preprogrammed methods : > 220
User programs : 50
Sample cell compatibility : 13 / 16 mm and 1 inch round adapter, 1 inch square and 10x10mm
Operating conditions : 10 to 40 °C (50 - 104 °F), max. 80 % relative humidity (non-condensing)
Storage conditions : -30 to 60 °C (-22 to 140 °F), max. 80 % relative humidity (non-condensing)
Enclosure rating : IP67
Dimensions (H x W x D) : 3.9 in x 7 in x 10.5 in (98 mm x 178 mm x 267 mm)
Weight : 3.31 lbs. (1.5 kg)
