Optical Design : Dual beam
Spectral Bandwidth : 2.0 nm
Light Source (Typical Lifetime) : XENON flash lamp (5 years typical)
Detector : Dual silicon photodiodes Dual silicon photodiodes
Wavelength
Range : 190 to 1100 nm
Accuracy : 0.5 nm
Repeatability : <±0.2 nm
Scanning Speed : Slow, medium and fast (up to 1600 nm/min)
Data Resolution : 0.2 nm, 0.5 nm, 1 nm, 2 nm, 5 nm
Photometric
Measurement Modes : Absorbance, % transmittance, concentration
Range : –2A to +3.5A; <1000 %T to 0 %T; 9999 C
Accuracy : ±0.002A at 0.5A, ±0.004A at 1.0A, ±0.008A at 2.0A
Drift : <0.0005 A/hr
Stray Light : < 1.0%T 198 nm (KCl) , <0.05%T at 220 nm (NaI), <0.03%T at 340 nm (NaNO2)
Display : 7-inch color touchscreen, fixed, high definition, 800 × 1280 pixels
Keypad : Glove compatible touchscreen
Connectivity : USB type A port for USB stick (front panel), Duplex USB type B port for computer (rear panel), Print via USB, Etheret or Wi-Fi
Dimensions (LxWxH) : 5.5 × 38.5 × 19.5 cm 5.5 × 38.5 × 19.5 cm
Weight : 7.5 kg
