Detector type : Dual Silicon Photodiodes
Display : 7-inch color touchscreen, fixed, high definition, 800 × 1280 pixels
Drift : (At 500 nm after 1 hour warmup) <0.0005A/Hr
Electrical requirements : External AC to DC converter. Voltage and Frequency (Hz) selected utomatically, 100–240 volts, 50–60 Hz.
Keypad : Touchscreen
Lamp : Tungsten-Halogen (>1000 hours)
Optical design : Dual beam
Photometric accuracy : ±0.002A at 0.5A
Instrument : ±0.004A at 1.0A & ±0.008A at 2.0A
Photometric display : -3A to +5A
Photometric range : –3A to +3.5A
Photometric repeatability : ±0.001A at 1A measured at 1.0A at 546 nm
Printer : Snap-on printer available
Spectral Bandwidth : 5 nm
Stray Light : <0.05%T at 340 nm and 400 nm
Wavelength accuracy : ±0.5 nm
Wavelength data interval : 0.2 nm, 0.5 nm, 1 nm, 2 nm, 5 nm
Wavelength range : 325 nm – 1100 nm
Wavelength repeatability : < ±0.2 nm
Wavelength Scan Speed : Automatic – up to 1800 nm/min
Dimensions (L x W) : 35.5 x 38.5 x 19.5 cm
Weight (metric) : 7.5 kg
