Wave length range : 190–1100 nm
Technics : Single beam with optical cuvette failure elimination
Lampe : Xenon Flash
Band width : 4 nm
Measurement modes : Concentration, absorbance, transmission, kinetics and spectra with abs. and % transmission, multi wavelength
Spectra/ Scans : Scans in 1 nm steps for freely defined wave length range
Barcode : Automatic recognition of Merck and WTW coded round and rectangular cuvettes, external barcode for other tests and sample-ID optional
Cuvettes : 16 mm round, rectangular 10 mm, 20 mm, 50 mm with automatic recognition, no adapter needed
Display : Backlit graphic display for comprehensive data evaluation
Data storage : 1000 values; for spectra + kinetics approx. 4 MB = 100 spectra (300 –900 nm) and 400 kinetics with 150 values each
Methods and profiles : over 150 programmable methods (starting with approx. 50), 100 user defined methods, 20 profiles each for kinetics + spectra
Update : via Internet und USB-Stick
Interfaces : 1 USB-A, 1 USB-B, 1 RS232
Protection class : IP31 and drain in optical compartments
Power supply : Country specific cables (EU continental, GB, US, AUS)
Temperature : Operating temperature +10°C to +35C, storage -25°C to +65°C
Dimensions : 404 x 197 x 314 mm (WxHxD)
Weight : approx. 3.7 kg w/o power supply
Accessories (Q4/2007) : PC-Software for easy data evaluation, rechargeable battery for UPS and portable use with ECO mode
