Optics : Grid monochromator with reference beam and beam splitter after exit slit
Measurement : Concentration, single and multi-wavelength measurement of absorbance and % transmission, kinetics, spectra
Wavelength Range : 190 - 1100 nm
Wavelength Resolution : 1 nm
Wavelength Accuracy : ± 1 nm on all Holmium peaks
Wavelength Reproducibility : better than 0,5 nm
Spectral Scope : 4 nm
Photometric Range : -3.3 - +3.3 Abs
Photometric Resolution : Absorption: 0.001 ; Transmission: 0.1 %
Photometric Accuracy : 0.003 Abs below 0.6 Abs ; 0.5 % from 0.6 to 2.0 Abs
Photometric Reproducability : 0.003 Abs below 0.6 Abs ; 0.5 % from 0.6 to 2.0 Abs
Photometric Linearity : < 1 % up to 2.0 Abs between 340 to 900 nm
Scan Speed : 700 - 2000 nm/min.
Stray Light : < 0.1 % Transmission at 340 and 408 nm
Drift : < 0.005 Abs per hour after 15 minutes heat up time
Operation : Membrane Keyboard
Display : 7“ high contrast colour graphic-display
Suitable Vials :
Rectangular Cuvettes 10 mm
Rectangular Cuvettes 20 mm
Rectangular Cuvettes 50 mm
Round Cuvettes 13 mm
Round Cuvettes 16 mm
Round Cuvettes 24 mm
Automatic Cuvette Recognition : Round cuvettes: 13, 16 and 24 mm ; Rectangular cuvettes: 10, 20 and 50mm
Test Recognition : via internal barcode reader
Interfaces :
Ethernet
USB B
USB A for External Memory
Keypad
Barcode-Scanner
PCL Compatible Printer
Auto-Check : Self-test at each switch-on: test of memory, processor, internal interface, filter lamp and additional calibration of each wavelength
LIMS Compatibility : ASCII, .csv-files
Internal Storage : approx. : 5000 data sets (method, user ID, date, result), autostorage function / manual storage function
Security : Password protection possible: 3 different user levels (guest, user, admin)
Power Drain : 100 - 240 V, 50/60 Hz
Power Supply : Buffer batteries (4 x AA), power supply unit with cable
Auto – OFF : Yes
Portability : Benchtop
Environmental Conditions : +10 °C to 35 °C (41 °F to 95 °F), ≤ 75 % average humidity within one year 95 %, max. 30 days/year, 85 % all other days
Stock Conditions : -25 °C to +65 °C (-13 °F to 268 °F)
Compliance : CE
Protection Class : IP 30
IP Protection Class : EN 60529
Interference Emission : Class B
Interference Immunity : IEC 61000-4-3
Tolerance Extension : 0.008 E
Meter Safety : EC Directive 2014/35/EC EN 61010-1:2010
Languages User Interface :
German, English, French, Spanish, Italian, Portuguese, Polish, Indonesian, Russian, Chinese, Japanese, Dutch, Swedish, Norwegian, Czech, Romanian, Macedonian, Slovenian, Hungarian, Turkish, Korean, Vietnamese, Thai, Serbian, Malaysian, Danish, Bulgarian
Languages Quick Start Guide :
German, English, French, Spanish, Italian, Portuguese, Polish, Indonesian, Russian, Chinese, Japanese, Dutch, Swedish, Norwegian, Czech, Romanian, Macedonian, Slovenian, Hungarian, Turkish, Korean, Vietnamese, Thai, Serbian, Malaysian, Danish, Bulgarian
Languages Full User Manual : German, English, Spanish, French, Italian, Portuguese, Chinese, Japanese
Dimensions : 422 x 195 x 323 mm
Weight : 4.5 kg
