Feed Water Requirements*
Water Inlet : Tap water: TDS<200 ppm (Extra pretreatment filter is recommended, if TDS>200 ppm)
Temperature : 5-45°C
Pressure : 1.0-4.0 Kgf/cm²
Flow Procedure** : PF+AC+RO+AC+UV+DI+TF
Ion rejection rate : 96%-99% (New RO membrane)
Organic rejection rate : >99%, when MW>200 Dalton
Particles and bacteria rejection rate : >99%
Bacteria : <0.1 cfu/ml
Output(25°C)**** : 94 L/hr
Pure water outlet : RO water and Ultrapure water
Standard configuration : Main body (Including 1 set of cartridges)+ 2 built-in15 liters tank +accessory bag
Power Consumption (W) : 120 W
Power Supply : AC110-220 V, 50/60 Hz
Note : *The feed water quality will influence the pure waters quality and cartridges life-span.**PF:polypropylene spun fiber, AC:active carbon, RO:reverse osmosis, DI:ion exchange, UV:ultraviolet, UF:ultrafiltration, TF:terminal microfiltration. ***Value of number will be influenced by temperature and feed water quality. ****All the specifications are tested under the situation:feed waters TDS=200ppm, 25°C, 50psi and 15% recovery rate.
Ultrapure Water Quality
Resistivity(25°C) : 18.2 MΩ.cm
Heavy Metal Ion : <0.1 ppb
TOC*** : <10 ppb
Particle (>0.2µm) : <1/ml
Endotoxin : -
Rnases : -
Dnases : -
Water Quality Monitor : -
Deionized water quality
Particle(>0.2µm) : -
DimensionLxWxH : 640x540x1110 mm
Weight : 70 kg
