Feed Water Requirements*
Water Inlet : Tap water: TDS<200 ppm (Extra pretreatment filter is recommended, if TDS>200 ppm)
Temperature : 5-45°C
Pressure : 1.0-4.0 Kgf/cm²
Bacteria : <0.1 cfu/ml
Output(25°C)**** : 10 L/hrs
Pure water outlet : 2:Electro Deionization water, ultrapure water
Standard configuration : Main body (Including 1 set of cartridges) + 20 liters tank+accessory bag
Power Consumption (W) : 120 W
Power Supply : AC110-220 V, 50/60 Hz
Note : *The feed water quality will influence the pure water's quality and cartridges life-span. **PF:polypropylene spun fiber, KDF:kinetic degradation fluxion, AC:active carbon, RO:reverse osmosis, SF:softener, EDI: electro deionization, UV:ultraviolet, DI:ion exchange, UF:ultrafiltration, TF:terminal microfiltration. ***Value of number will be influenced by temperature and feed water quality. ****All the specifications are tested under the situation:feed water's TDS=200ppm, 25°C, 50psi and 15% recovery rate.
Ultrapure Water Quality
Heavy Metal Ion : <0.1 ppb
TOC*** : <30 ppb
Endotoxin : -
Rnases : -
Dnases : -
Feed Water Requirements
Resistivity (25°C) : 18.2 MΩ.cm
TOC* : -
Particle (>0.1µm) : <1/ml
Flow procedure** : PF+KDF+AC+RO+SF+EDI+DI+TF
EDI water quality
Resistivity*** : >5 MΩ.cm
Silicon rejection rate : >99.9%
Water Quality Monitor : -
Flow Procedure** : -
DimensionLxWxH : 500x360x540 mm
Weight : 30 kg
