Feed Water Requirements*
Water Inlet : Tap water: TDS<200 ppm (Extra pretreatment filter is recommended, if TDS>200 ppm)
Temperature : 5-45°C
Pressure : 1.0-4.0 Kgf/cm²
Flow Procedure** : PF+AC+RO +UV+DI+UF+TF
Ion rejection rate : 96%-99% (New RO membrane)
Organic rejection rate : >99%,when MW>200 Dalton
Particles and bacteria rejection rate : >99%
Bacteria : <0.1 cfu/ml
Output(25°C)**** : 30 L/hrs
Pure water outlet : RO water and Ultrapure water
Water Quality Monitor : Portable TDS/conductivity test pen + on-line resistivity monitor
Standard configuration : Main body (Including 1 set of cartridges)+15 liters tank+ TDS pen +accessory bag
Power Consumption (W): 72 W
Power Supply : AC110-220 V, 50/60 Hz
Note : *The feed water quality will influence the pure water's quality and cartridges life-span. **PF:polypropylene spun fiber, AC:active carbon, RO:reverse osmosis, DI:ion exchange, UV:ultraviolet, UF:ultrafiltration, TF:terminal microfiltration. ***Value of number will be influenced by temperature and feed water quality. ****All the specifications are tested under the situation:feed water's TDS=200ppm, 25°C, 50psi and 15% recovery rate.
Ultrapure Water Quality
Resistivity(25°C) : 18.2 MΩ.cm
TOC*** : <3 ppb
Heavy metal ion : <0.1 ppb
Flow rate : 2.0 L/min (with pressure tank)
Endotoxin : <0.001 EU/ml
Rnases : <0.01 ng/ml
Dnases : <4pg/µl
Dimension (LxWxH) : 410x220x420 mm
Weight : 20 kg
