Water purification method : Adsorption by means of spherical activated carbon, catalyst, reverse osmosis, deionization,
UV irradiation, optional end-position particle and sterile filtration
Power supply : 100 – 240 VAC (± 10 %); 50 – 60 Hz, 130 VA (max.)
Operating temperature : 2°C – 35 °C at max. 80 % relative humidity
Storage temperature : 5°C – 45 °C at max. 80 % relative humidity
Data output : SD card slot, RS-232 interface
Water type : ASTM Type 1 ultrapure water - Type 3 pure water
Output : 120 l/h - 8 or 16 l/h
Water dispensing flow rate : up to 2 l/min - up to 3 l/min
Volume-controlled dispensing : 2 l/min in 100 ml, 1 l or 5 l steps, depending on the total amount removed between 0.1 l and 60 l
Volume accuracy : 3 % between 0.25 l and 60 l
Typical conductivity : < 20 μS/cm
Typical resistivity : < 0.05 MO + cm
Conductivity : 0.055 μS/cm compensated to 25°C
Resistivity : 18.2 MO + cm compensated to 25 °C
TOC content (system with UV lamp) : < 2 ppb
TOC content (system without UV lamp) : < 5 ppb
Microorganism content : < 1 CFU/1,000 ml - < 1 CFU/1,000 ml
Particle content : < 1/ml - < 1/ml
Typical ion retention : up to 98%
Retention of dissolved organic substances (MW > 300 Dalton) : 99%
Particle and microorganism retention : 99%
Input pressure : 0.5 – 6.9 bar, recommended > 2 bar
Temperature : 2 – 30 °C
Specific conductivity : < 1,500 μS/cm compensated to 25 °C
TOC : < 2,000 ppb
Max. total hardness (max. CaCO3) : 360 ppm
Free chlorine : < 4 ppm
Iron (total Fe content) : < 0.1 ppm
Fouling Index (SDI) : < 5
Turbidity : <1 NTU
pH value : 4 – 10
Dimensions width + height + depth : 43.5 + 50.1 + 47.6 cm
Empty weight : approx. 23 kg
Operating weight : approx. 31 kg
