Water purification method : Adsorption by means of spherical activated carbon, catalyst, reverse osmosis, ion exchange,
optional UV irradiation, and end-position particle | sterile filtration
Power supply : 100 – 240 VAC; 50 and 60 Hz, 2 A (max.)
Operating temperature : 2°C – 35 °C at max. 80% relative humidity
Storage temperature : 5°C – 45 °C at max. 80% relative humidity
Water type : ASTM Type 1 ultrapure water - Type 3 pure water
Production output : Up to 8 l/h
Water dispensing flow rate : Up to 1.0 l/min - Depressurized via ball valve
Volume-controlled dispensing : 50 ml steps, between 0.05 and 5 l
Volume accuracy : ± 3 % between 0.25 and 5 l
Typical conductivity : 0.055 μS/cm compensated to 25 °C - < 20 µS/cm7
Typical resistivity : 18.2 MO × cm compensated to 25 °C - < 0.05 MO × cm7
TOC content (system with UV lamp) : < 5 ppb
Microorganism content : < 1 CFU/1,000 ml < 1 CFU/1,000 ml
Particle content > 0.2 µm : < 1/ml - m< 1/ml
Typical ion retention : Up to 98%
Retention of dissolved organic substances (MW > 300 Dalton) : 99 %
Particle and microorganism retention : 99 %
Input pressure : 0.5 – 6 bar, recommended > 2 bar
Temperature : 2 – 30°C
Specific conductivity : < 1500 µS/cm compensated to 25 °C
TOC : < 2,000 ppb
Max. total hardness (max. CaCO3) : 360 ppm
Free chlorine : < 4 ppm
Iron (total Fe content) : < 0.1 ppm
Fouling Index (SDI) : < 10
Turbidity : <1 NTU
pH value : 4 – 10
Dimensions width × height × depth : 280 × 509.4 × 530.7 mm
Empty weight : Approx. 13 kg
Operating weight : Approx. 23 kg
