Water purification method : Adsorption by means of spherical activated carbon, deionization, optional end-position
particle and sterile filtration
Water type : ASTM Type 1 ultrapure water
Output : 120 l/h
Power supply : 100 – 240 VAC (± 10 %); 50 – 60 Hz, 130 VA (max.)
Operating temperature : 2 °C – 35 °C at max. 80 % relative humidity
Storage temperature : 5 °C – 45 °C at max. 80 % relative humidity
Data output : SD card slot2, RS-232 interface
Input pressure : 0 – 6.9 bar, recommended > 2 bar
Temperature : 2 – 30 °C
Specific conductivity : < 100 μS/cm compensated to 25 °C
TOC : < 50 ppb
Turbidity : < 1 NTU
pH value : 4 – 10
Water dispensing flow rate : 0.1 – 2 l/min, adjustable
Volume-controlled dispensing : 2 l/min in 100 ml, 1 l or 5 l steps, depending on the total dispense between 0.1 l and 60 l
Volume accuracy : 3% between 0.25 l and 60 l
Conductivity : 0.055 μS/cm compensated to 25 °C
Resistivity : 18.2 MO + cm compensated to 25 °C
TOC : < 5 ppb
Microorganism content : < 1 CFU/1,000 ml
Particle content : < 1/ml
Dimensions width + height + depth : 35.0 + 49.2 + 45.1 cm
Empty weight : 17 – 19 kg, depending on the device type
Operating weight : 27 – 29 kg, depending on the device type
